Product Specifications
Performance
| Refrigeration Capacity | Input Power | Efficiency | EVAP TEMP | COND TEMP | AMBIENT TEMP | RETURN GAS | LIQUID TEMP | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Condition | Test Voltage | Btu/h | kcal/h | W | W | Btu/Wh | kcal/Wh | W/W | |||||
| EN12900 | 230V ~ 60HZ | 4778 | 1204 | 1400 | 488 | 9.79 | 2.47 | 2.87 | 5°C (41°F) | 50°C (122°F) | 32°C (90°F) | 15°C (59°F) | 50°C (122°F) |
| EN12900 | 230V ~ 50HZ | 3771 | 950 | 1105 | 461 | 8.18 | 2.06 | 2.4 | 5°C (41°F) | 50°C (122°F) | 32°C (90°F) | 15°C (59°F) | 50°C (122°F) |
General
Evaporating Temp. Range: | -15°C to 15°C (5°F to 59°F) |
Motor Torque: | Low Start Torque (LST) |
Compressor Cooling: | Fan |
Mechanical
Weight: | 12 |
Weight Unit of Measure: | KG |
Displacement (cc): | 11.4 |
Oil Type: | Polyvinylether |
Viscosity (cSt): | 68 |
Oil Charge (cc): | 414 |
Electrical
Voltage Range (50 Hz): | 207-253 |
Voltage Range (60 Hz): | 207-253 |
Locked Rotor Amps (LRA): | 25 |
Rated Load Amps (RLA 50 Hz): | 2.6 |
Rated Load Amps (RLA 60 Hz): | 3.8 |
Max. Continuous Current (MCC in Amps): | 5.6 |
Motor Resistance (Ohm) – Main: | 2.5 |
Motor Resistance (Ohm) – Start: | 6.7 |
Motor Type: | PSC |
Overload Type: | N/A |
Relay Type: | N/A |
Agency Approval
| CCC Listed, CE Listed, UL Recognized |
